IC HydroC: comparison
Platinum-free hydrogen power, built for harsh environments
The lightest air-cooled PEM stack we know of, and the only one proven at −40 °C
Key stats:
1,500 W/kg
Power-to-weight
-40°C
Cold start and flight
Pt-free
Cathode catalyst
6kg
UAV payload
Why platinum-free matters
Oxygen reduction at the cathode is the slowest step in a fuel cell, so it needs a catalyst. Platinum works but is costly. Iron–nitrogen–carbon (Fe‑N‑C) catalysts avoid platinum; the concave design brings active sites to the surface where oxygen can reach them.
Power-to-weight
Intelligent Core HYDROC
Pt-free · UAV
Pt-free · UAV
1,500W/kg 1
IE-SOAR 800W2
UAV
UAV
552
IE-SOAR 1.2kW
UAV
UAV
444
H3 Aerocell A-15003
UAV
UAV
429
Atomfair FCS-3074
Light EV · forklift · backup
Light EV · forklift · backup
375
1. Rated continuous power ÷ published mass
2. IE SOAR data sheet
3. H3 Aerocell data sheet
4. Atomfair data sheet
2. IE SOAR data sheet
3. H3 Aerocell data sheet
4. Atomfair data sheet
Complete UAV comparison
Max payload
Endurance
Range
Min temp
Intelligent Core HYDROC
6kg
150 - 180min
70-80km
-40°C
Cellen H2-61
5kg
150min
Not published
-5°C
Doosan DS30W2
3kg
120min
Up to 80km
-5°C
H3 Hycopter3
2.5kg
~180min
Not published
Not published
Temperature envelope
°C
-40
0
+50
Intelligent Core HYDROC
IE-SOAR1
Doosan DS30W2
Cellen H2-63
Atomfair FCS-3074
Intelligent Core HYDROC specifications
Type
Air-cooled PEM stack, Pt-free cathode
Power-to-weight
Up to 1,500 W/kg
Volumetric power
1,350 W/L
System energy density
>1,000 Wh/kg
Hydrogen utilisation
97.5% (closed-loop FCU)
Operating range
-40°C to +50°C
Power response
Millisecond-level (hybrid management)
